Beschreibung

Model              T600         T800          T1000

Two-channel Mode

8OHMper Channel：                      600Wx2        800Wx2        1000Wx2

4OHMper Channel：        1200Wx2       1600Wx2        2000Wx2

 8OHM Bridge：           1200W         1600W                      2000W

OTHER PARAMETERS

DAMPING：             400:1        500:1         500:1

Frequency Response： 20Hz-20KHz[+0/-0.3dB,1W/80)

Input Sensitivity：         0.77V         1V           1V

Input impediance： ≥20K/≥10K

SNR：              -100dB

Connection and Protection

Connector：Output 4 cores Enter XLR3 pin

Cooling：The cooling mode stepless speed regulating fan, airflow from the back to the front

Amp protection： Direct current/short circuit/overheat/ overload/fuse/ startup& shutdown

Light Signal ：Signal/ compress/ protection/overheat

Main Power Supply： AC-200-240V/50-60Hz

Size and Weight

Dimensions (mm) :             472Wx483Dx88H           472Wx483Dx88H          472Wx483Dx88H

N.W(KG)：           20KG             22KG         24KG
